Dynamic Measurement & Signal Analysis

Handheld to high channel solutions with patented technologies. Vibration, strain, acoustic & more.

Vibration Testing

Single or multi axis vibration testing, combined temperature & humidity

Machine Vibration Monitoring

Route based vibration data collection, condition monitoring, vibration diagnostics.

Modal Testing & Modal Analysis

Single or multi axis FRF testing, hammer impact testing, geometry & ODS (operational deflection shape)



EDM 12.0 Release

  • [DSA] GRS v2 with Remote Interaction Support

  • [DSA] GPS Time-stamped signals for Synchronized Data Acquisition

  • [DSA] Introducing IEEE 1588 Time Synchronization with a grand master clock, allowing for up to 100 ns accuracy

  • [VCS] Stockbridge Damper Testing

  • [VCS] Energy-Efficient Shaker System

  • [ALL] Secure Recording Using RAID on Spider-NAS

  • [ALL] Raw Time Recording to PC

  • [EMA] Operational Modal Analysis with CoCo Handheld Systems

  • [PA] Custom Data Conditioning with Python Scripts

  • [PA] Support for Timestamped Signals

  • Signal Viewer

  • 12 new EDM Extensions to support more temperature chambers, water chillers, charge cabinets, and other features


(Product Note #002, 50 pages, 2.34 MB)
Describes the advanced dynamic signal analysis theory including swept sine test with tracking filter, real-time digital filters, octave analysis, sound level meters, order tracking analysis, automated test, shock response spectrum analysis. Read online here.


(Product Note #087, 8 pages, 1.18 MB) Intelligent Clipping modifies the drive signal to minimize the loss in dynamic range of the profile. Read online here.


(Product Note #088, 19 pages, 1.64 MB) Digital filters are powerful tools utilized during the data conditioning phase to analyze signals. Read online here.

Vibration Diagnostics Systems (VDS) 1.12

  • Fixed Threshold (Alarms)

  • Machine Trend Redesign

  • Signal Trend Graph Improvements
