Vibration Testing System with Head Expander

Water-cooled; high-pressure 2500 x 2500 mm monobase slip table, w/optional automatic armature centering, motorized gearbox for shaker rotation, and foundation mounting or air-isolation mounts + 2500 mm square magnesium head expander.


    E20064A-PA3280-HST2500 System Performance
    Metric
    Imperial


    Sine Force Peak kN (lbf)
    196
    44,000


    Random Force rms kN (lbf)
    196
    44,000


    Shock Force (6ms) kN (lbf)
    392
    88,000


    Useful Frequency Range Hz
    5-2200
    5-2200


    Continuous Displacement mm (in)
    51
    2.0


    Shock Displacement mm (in)
    51
    2.0


    Max Velocity m/s (in/s)
    2
    78.7


    Max Acceleration Sine Peak m/s² (g)
    980
    100


Continuous displacement 51 mm (2.0 in)/76 mm (3.0 in)
Usable frequency range 5 - 2200 Hz
Max static payload 2000 kg (4409 lb)
Air-cooled amplifier efficiency > 90%
Rugged isolated trunnion

Key Applications:

The E-Series water-cooled electro-dynamic shakers are designed for the vibration testing of large-sized payloads up to 6000 kg (13,200 lb).
Ideally suited to test large-sized electronic parts, connectors, hand-held units and mechanical assemblies.

Vibration Testing System with Head Expander

Air-cooled system ideally suited to test small sized electronic parts, connectors, hand-held units and small mechanical assemblies. Featuring HES1200M-1000/560 Head Expander.

Continuous displacement 51 mm (2.0 in)
Useable frequency range 5 - 5000 Hz
Max static payload 200 kg (441 lb)
Air-cooled amplifier efficiency > 90%
Rugged isolated trunnion


    L0620M-PAS106 System Performance
    Metric
    Imperial

    Sine Force Peak kN (lbf)
    5.88
    1,320

    Random Force rms kN (lbf)
    5.88
    1,320

    Shock Force (6ms) kN (lbf)
    11.76
    2,640

    Useful Frequency Range Hz
    5-5000
    5-5000

    Continuous Displacement mm (in)
    51
    2

    Shock Displacement mm (in)
    51
    2

    Max Velocity m/s (in/s)
    2
    78.7

    Max Acceleration Sine Peak m/s² (g)
    980
    100

MIMO (Multiple-Input Multiple-Output) Vibration Testing System

Air-cooled simultaneous three-axis vibration testing system simulates real-world environments and satisfies MIL-STD-810G test requirements. It reduces test time by two-thirds for significant cost savings. Features Crystal Instruments’ Spider vibration test controller for advanced MIMO vibration test control.


    MA-1000-4H System Performance
    Metric
    Imperial


    Sine Force Peak per Axis kN (lbf)
    9.8
    2,203


    Random Force rms per Axis kN (lbf)
    6.86
    1,540


    Shock Force Peak per Axis kN (lbf)
    14.7
    3,305


    Max Useful Frequency Range Hz
    5-2000
    5-2000


    Max Displacement (pk - pk) mm (in)
    51
    2


    Max Velocity m/s (in/s)
    1
    4


    Max Static Payload kg (lb)
    70
    154


Max pk-pk displacement 51 mm (2 in)
Usable frequency range 5 - 2000 Hz
Max static payload 70 kg (154 lb)
Air-cooled amplifier efficiency > 90%
Air-isolation feet to eliminate need for seismic floor

MESA Vibration Testing System

Air-cooled system performs multiple-exciter single-axis (MESA) vibration testing for medium-sized electronic parts, flight and ground vehicle components and assemblies.


    M5044A-PA155-LST900M System Performance
    Metric
    Imperial


    Sine Force Peak kN (lbf)
    49
    11,010


    Random Force rms kN (lbf)
    49
    11,010


    Shock Force (6ms) kN (lbf)
    98
    22,000


    Useful Frequency Range Hz
    5 - 2500
    5 - 2500


    Continuous Displacement mm (in)
    51
    2


    Shock Displacement mm (in)
    51
    2


    Max Velocity m/s (in/s)
    2
    78.7


    Max Acceleration Sine Peak m/s² (g)
    980
    100


Continuous displacement 51 mm (2.0 in)
Useable frequency range 5 - 2500 Hz
Max static payload 1000 kg (2205 lb)
Air-cooled amplifier efficiency > 90%
Rugged isolated trunnion

Temperature, Humidity, & Vibration (THV) Testing System

Temperature testing services range from -70 °C to 150 °C. The lab features advanced Sentek Dynamics testing chambers with combined environmental testing capabilities. The AGREE Chamber (5° C/min) is combined with a 32 kN shaker featuring an 800 x 800 mm low-pressure slip table. Testing services can include combined testing according to the AGREE (Advisor Group on Reliability of Electronic Equipment) method of testing, which combines three testing environments (temperature testing, humidity testing, and vibration testing) in one chamber. One comprehensive testing report is provided.


    THV-1200-5 Specifications

    Internal Volume (L)
    1200

    Interior Dimensions WxDxH (mm)
    1100x1100x1000

    Temperature Range (ᴼC)
    -70 to 150

    Temperature Fluctuation (ᴼC)
    ± 0.5

    Temperature Uniformity (ᴼC)
    ≤2

    Temperature Deviation (ᴼC)
    ± 2

    Temperature Ramp Rate (ᴼC)/min) from -45ᴼC to 80ᴼC)
    5

    Humidity Range (%RH)
    20 to 98

    Humidity Deviation (%RH)
    ± 2 to 3 (> 75)

    ± 5 (≤75)


   M3240A System Performance
    Metric
    Imperial


    Sine Force Peak kN (lbf)
    31.36
    7050


    Random Force rms kN (lbf)
    31.36
    7050


    Shock Force (6ms) kN (lbf)
    62.72
    14100


    Useful Frequency Range Hz
    5-2500
    5-2500


    Continuous Displacement mm (in)
    51
    2


    Shock Displacement mm (in)
    51
    2


    Max Velocity m/s (in/s)
    2
    78.7


    Max Acceleration Sine Peak m/s² (g)
    980
    100
